IMPORTANT
Команду рекомендуется использовать совместно с logging buffered
size. На системах, находящихся в эксплуатации, не следует задавать
чрезмерно большие значения (60000 KiB и более); вместо этого
рекомендуется использование удаленных серверов журналирования.
7.7. logging cli-commands
Данной командой включается учет введенных пользователями команд в системе
журналирования событий.
Использование отрицательной формы команды отключает учет введенных пользователем
команд в системе журналирования устройства.
Синтаксис
[no] logging cli-commands
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# logging cli-commands
7.8. logging console
Данная команда задает минимальную степень важности (severity) сообщений, выводимых
на аппаратную консоль устройства.
Заданная степень важности используется в качестве фильтра — все системные события,
имеющие важность равную или более высокую, чем заданная, подлежат выводу на
аппаратную консоль.
Согласно RFC3164 имеются следующие стандартные значения степеней важности:
86
