*no bundle mode
Параметры
• active — порт включается в активном режиме LACP;
• passive — порт включается в пассивном режиме LACP;
• off — порт включается в режиме статической агрегации, без использования
протокола LACP.
Необходимый уровень привилегий
p10
Командный режим
config-lacp-interface
Пример
0/ME5100:example_router01(config)# lacp interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# bundle mode active
0/ME5100:example_router01(config-tengigabitethernet)#
24.5. collector-max-delay
Максимальное время между отправкой последовательных сообщений в физический порт
из Frame Collector. Задаётся в десятках микросекунд.
Отрицательная форма команды устанавливает значение по умолчанию (0).
Синтаксис
collector-max-delay INT (0-65535)
*no collector-max-delay*_
Параметры
• INT (0-65535) — Задание времени
Необходимый уровень привилегий
p10
Командный режим
config-lacp-interface
Пример
0/ME5100:example_router01(config)# lacp interface bundle-ether 1
0/ME5100:example_router01(config-bundle-ether)# collector-max-delay 32768
0/ME5100:example_router01(config-bundle-ether)#
520
