![Eltex ME5100 [214/670] Authentication key](/views2/1569351/page214/bgd6.png)
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# admin-tag 15
0/ME5100:example_router01(config-tengigabitethernet)#
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# summary-address 10.0.0.0/8
0/ME5100:example_router01(config-summary-address)# admin-tag 10
0/ME5100:example_router01(config-summary-address)#
12.5. authentication-key
В режиме конфигурации определенного уровня IS-IS для всего протокола (config-router-isis-
level и config-router-isis-vrf-level) данная команда задает ключ, используемый для
аутентификации методом, указанным в authentication-type.
В режиме конфигурации определенного уровня IS-IS для интерфейса (config-router-isis-
interface и config-router-isis-vrf-interface) данная команда задает ключ, используемый для
аутентификации методом, указанным в authentication-type.
В режиме конфигурации определенного уровня IS-IS для всего протокола (config-router-isis-
level и config-router-isis-vrf-level) отрицательная форма команды удаляет из конфигурации
ключ для аутентификации.
В режиме конфигурации определенного уровня IS-IS для интерфейса (config-router-isis-
interface и config-router-isis-vrf-interface) отрицательная форма команды удаляет из
конфигурации ключ для аутентификации.
Синтаксис
authentication-key { STRING | encrypted HEX_STRING }
[no] authentication-key
Параметры
• STRING — clear-text пароль, используемый для аутентификации (1..20);
• HEX_STRING — строковое представление зашифрованного ключа (2..40).
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface
config-router-isis-interface-level
config-router-isis-level
config-router-isis-vrf-interface
config-router-isis-vrf-interface-level
config-router-isis-vrf-level
193
