• tcp — TCP протокол
• udp — UDP протокол
• any — любой протокол
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-entry)# protocol tcp
0/FMC0:example_router01(config-entry)#
22.10. remark
Команда задает строковое описание правилу списка доступа.
Отрицательная форма команды удаляет описание.
Синтаксис
remark DESCRIPTION
no remark
Параметры
• DESCRIPTION — строковое описание (1..64)
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-entry)# remark "Example description"
0/FMC0:example_router01(config-entry)#
22.11. source
Команда задает префикс для сравнения IP-адреса источника пакета в правиле списка
доступа.
491
