![Eltex ME5200 [194/670] Set ospf tag](/views2/1569351/page194/bgc2.png)
Отрицательная форма команды удаляет данное значение из конфигурации, при этом сразу
же применяется router ID по умолчанию. Порядок выбора по умолчанию:
1. старший IPv4-адрес Loopback-интерфейса;
2. IPv4-адрес Loopback-интерфейса;
3. старший IPv4-адрес интерфейса (кроме Loopback);
4. IPv4-адрес интерфейса (кроме Loopback).
Синтаксис
router-id IPv4_FORMAT
no router-id
Параметры
◦ IPv4_FORMAT — значение router ID в формате IPv4-адреса.
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2
config-router-ospfv2-vrf
config-router-ospfv3
config-router-ospfv3-vrf
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)#router-id 10.1.1.1
0/ME5100:example_router01(config-ospfv2)#
NOTE Нельзя использовать 0.0.0.0 в качестве OSPF router-id.
IMPORTANT
При изменении OSPFv2 router ID все OSPF-соседства разрываются и
переустанавливаются заново, что приводит к перерыву трафика через
устройство. Команду следует использовать с осторожностью.
11.64. set ospf-tag
Данная команда позволяет установить tag для всех маршрутов, которые попадают под
данное правило редистрибуции.
Отрицательная форма команды устанавливает tag в значение по умолчанию (0).
Синтаксис
set ospf-tag TAG
no set ospf-tag
173
