Eltex ME5100 [420/670] Mpls static label local
![Eltex ME5000 [420/670] Mpls static label local](/views2/1569351/page420/bg1a4.png)
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# mac limit maximum 60000
0/ME5100:example_router01(config-bridge-domain)#
15.21. mpls static label local
Данная команда позволяет задать в конфигурации статическое значение локальной MPLS-
метки для pseudowire. Команда применяется при использовании manual конфигурации
псевдопровода.
Отрицательная форма команды удаляет данную настройку.
Синтаксис
mpls static label local LABEL
no mpls static label local
Параметры
• LABEL — значение MPLS-метки.
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-pw
config-l2vpn-bridge-domain-pw-backup-pw
config-l2vpn-bridge-domain-vfi-pw
config-l2vpn-bridge-domain-vfi-pw-backup-pw
config-l2vpn-xconnect-group-p2p-pw
config-l2vpn-xconnect-group-p2p-pw-backup-pw
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# pw 171.16.0.2 100
0/ME5100:example_router01(config-pw)# mpls static label local 20
0/ME5100:example_router01(config-pw)#
399
