Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show processes memory
Mon May 8 15:00:08 2017
Ê Unit Process Allocated, kB
Ê -------- --------------------- --------------
Ê 0/ME5100 pp-manager 1181056
Ê 0/ME5100 dcsi 92672
Ê 0/ME5100 netconfd 42560
Ê 0/ME5100 if-manager 17344
Ê 0/ME5100 PCT_CSS 14950.92
Ê<...>
2.15. show redundancy
Данная команда показывает оперативное состояние резервирования модулей управления
маршрутизатора. Модуль управления маршрутизатора может находиться в режимах:
MASTER — модуль является ведущим; SLAVE — модуль является ведомым и находится в
режиме горячего резерва; STANDALONE — модуль работает в системе, не поддерживающей
резервирования модулей управления.
Синтаксис
show redundancy
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
18
