![Eltex ME5000 [249/670] Priority](/views2/1569351/page249/bgf9.png)
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/8.10
0/ME5100:example_router01(config-tengigabitethernet-sub)# point-to-point
0/ME5100:example_router01(config-tengigabitethernet-sub)#
12.58. priority
В режиме конфигурации lfa filter (config-router-isis-address-family-unicast-lfa-filter и config-
router-isis-vrf-address-family-unicast-lfa-filter) данная команда устанавливает приоритет для
правила фильтрации.
В режиме конфигурации redistribution (config-router-isis-address-family-unicast-redistribution и
config-router-isis-vrf-address-family-unicast-redistribution) данная команда устанавливает
приоритет для правила редистрибуции.
В режиме конфигурации уровня IS-IS для интерфейса, участвующего в IS-IS процессе (config-
router-isis-interface и config-router-isis-vrf-interface) данная команда устанавливает
приоритет для данного маршрутизатора при выборе Designated Intermediate System (DIS)
маршрутизатора.
В режиме конфигурации lfa filter (config-router-isis-address-family-unicast-lfa-filter и config-
router-isis-vrf-address-family-unicast-lfa-filter) отрицательная форма команды возвращает
значение по умолчанию (2147483646).
В режиме конфигурации redistribution (config-router-isis-address-family-unicast-redistribution и
config-router-isis-vrf-address-family-unicast-redistribution) отрицательная форма команды
возвращает значение по умолчанию (2147483646).
В режиме конфигурации уровня IS-IS для интерфейса, участвующего в IS-IS процессе (config-
router-isis-interface и config-router-isis-vrf-interface) возвращает значение по умолчанию (64).
Синтаксис
priority PRIORITY
no priority
Параметры
• PRIRORITY — значение приоритета.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-unicast-lfa-filter
config-router-isis-vrf-address-family-unicast-lfa-filter
config-router-isis-address-family-unicast-redistribution
config-router-isis-vrf-address-family-unicast-redistribution
