17.4. interface
Данная команда явно указывает, с какого интерфейса устанавливать BFD-сессию.
Применимо для работы с IS-IS.
Отрицательная форма команды удаляет интерфейс из конфигурации профиля.
Синтаксис
interface {fourtygigabitethernet | gigabitethernet | hundredgigabitethernet |
tengigabitethernet | bundle-ether} DEVICE/SLOT/PORT[.SUB]
no interface {fourtygigabitethernet | gigabitethernet | hundredgigabitethernet |
tengigabitethernet | bundle-ether} DEVICE/SLOT/PORT[.SUB]
Параметры
• DEVICE/SLOT/PORT[.SUB] — номер шасси/номер слота/номер порта [.номер
сабинтерфейса]
Необходимый уровень привилегий
p10
Командный режим
config-bfd-session
Пример
0/ME5100:example_router01(config)# bfd session test
0/ME5100:example_router01(config-session)# interface tengigabitethernet 0/0/1.101
0/ME5100:example_router01(config-session)#
17.5. multiplier
Данная команда позволяет установить множитель для BFD-сессии. Если за время, равное
произведению значения множителя и rx-interval, не пришло ни одного BFD Control пакета,
то BFD сессия переходит в состояние Down.
Отрицательная форма команды возвращает значение по умолчанию (2).
Синтаксис
multiplier NUMBER
no multiplier
Параметры
• NUMBER (2-50) — число, которое определяет множитель BFD сессии.
Необходимый уровень привилегий
p10
432
