Eltex ME5100 [516/670] Broadcast rate
![Eltex ME5100 [516/670] Broadcast rate](/views2/1569351/page516/bg204.png)
Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-qos-policy-map-class
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# policy-map POLICY-MAP-01
0/ME5100:example_router01(config-policy-map)# class TEST
0/ME5100:example_router01(config-class)# bandwidth strict-priority
0/ME5100:example_router01(config-class)#
23.3. broadcast rate
Команда задает ограничение полосы пропускания broadcast трафика в правиле шторм-
контроля. Модификатор burst* задает размер допустимых вспышек broadcast трафика.
Отрицательная форма команды снимает ограничение
Синтаксис
broadcast rate KBPS [ burst KBITS ]
no broadcast rate
Параметры
• KBPS — полоса пропускания в килобитах в секунду (64..300000000)
• KBITS — размер вспышки в килобитах (0..33292)
Необходимый уровень привилегий
p10
Командный режим
config-qos-storm-control
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# storm-control Test
0/ME5100:example_router01(config-storm-control)# broadcast rate 1000 burst 64000
0/ME5100:example_router01(config-storm-control)#
495
