обратного отсчёта сбрасывается, конфигурация считается успешно примененной и
сохраняется в энергонезависимую память. Если таймер обратного отработает до конца и
повторной команды 'commit' не последует, то изменения будут отменены (произойдет
возврат к предыдущей конфигурации) и кандидат-конфигурация будет очищена.
Синтаксис
commit [ confirmed SECS ] [ replace ]
Параметры
• confirmed SECS — применить конфигурацию с последующим подтверждением.
Таймер обратного отсчета запускается на <SECS> секунд;
• replace — провести операцию замены текущей конфигурации на конфигурацию,
представляющую собой слияние настроек по умолчанию и изменений, внесенных в
текущих сессиях редактирования. Изменения, внесенные в текущих сессиях
редактирования, можно просмотреть командой 'show configuration changes'. Таким
образом, команда 'commit replace' может быть применена для сброса конфигурации
устройства. Команду следует использовать с осторожностью.
Необходимый уровень привилегий
p15
Командный режим
ANY-CONFIG
Пример
0/ME5100:example_router01(config)# commit confirmed 30
Wed May 10 15:10:28 2017
Commit successfully completed in 0.092728 sec
0/ME5100:example_router01(config)# commit
Wed May 10 15:10:30 2017
Commit successfully completed in 0.115530 sec
3.6. copy
Данная команда служит для копирования файлов между различными источниками и
местами назначениями. Команда позволяет произвести копирование конфигураций и
образов ПО.
Синтаксис
copy SOURCE DESTINATION [ vrf VRF_NAME ]
Параметры
• SOURCE — источник, возможны следующие варианты:
◦ fs://running-config — действующая конфигурация устройства;
30
