Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain
config-l2vpn-bridge-domain-vfi
config-l2vpn-xconnect-group-p2p
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# vfi test
0/ME5100:example_router01(config-vfi)# shutdown
0/ME5100:example_router01(config-vfi)#
15.38. signaling-protocol bgp ve-id
В режиме конфигурации параметров BGP Auto-discovery бридж-домена или кросс-коннекта
данная команда включает BGP сигнализацию и позволяет задать идентификатор сайта (VE
ID).
Отрицательная форма команды удаляет данный элемент конфигурации.
Синтаксис
signaling-protocol bgp ve-id VE_ID
no signaling-protocol bgp ve-id
Параметры
• VE_ID — локальная VE ID (1..65535)
Необходимый уровень привилегий
p10
Командный режим
config-l2vpn-bridge-domain-autodiscovery-bgp
config-l2vpn-xconnect-group-p2p-autodiscovery-bgp
Пример
0/ME5100:example_router01(config)# l2vpn bridge-domain test
0/ME5100:example_router01(config-bridge-domain)# autodiscovery bgp
0/ME5100:example_router01(config-bgp)# signaling-protocol bgp ve-id 200
0/ME5100:example_router01(config-bgp)#
15.39. storm-control
Команда включает шторм-контроль трафика в бридж-домене и входит в режим ввода
414
