Пример: настройка системного имени (hostname)
EOS login: admin
Password:
********************************************
* Welcome to ME5100 *
********************************************
0/ME5100:EOS# config
0/ME5100:EOS(config)# hostname example_router01
0/ME5100:EOS(config)# do show configuration changes
Tue Jan 18 21:37:19 2000
hostname example_router01
0/ME5100:EOS(config)# commit
Tue Jan 18 21:37:23 2000
Commit successfully completed in 0.031951 sec
0/ME5100:example_router01(config)# end
0/ME5100:example_router01#
1.5. Именование интерфейсов
При работе маршрутизатора используются сетевые интерфейсы различного типа и
назначения. Система именования позволяет однозначно адресовать интерфейсы по их
функциональному назначению и местоположению в системе. Далее в таблице приведен
перечень типов интерфейсов.
Таблица 4. Поддерживаемые типы интерфейсов
Тип интерфейса Обозначение и функционал
Физические интерфейсы Обозначение физического интерфейса включает в себя его тип
и идентификатор.
Идентификатор имеет вид <UNIT>/<SLOT>/<PORT>, где:
• <UNIT> - номер устройства в кластере устройств;
• <SLOT> - номер модуля в составе устройства;
• <PORT> - порядковый номер интерфейса данного типа в
модуле.
Физические интерфейсы всегда присутствуют в системе.
Интерфейсы Ethernet
10Гбит/с
tengigabitethernet <UNIT>/<SLOT>/<PORT>
Пример обозначения: 'tengigabitethernet 0/0/10'. Допускается
использовать сокращенную форму с обязательным пробелом,
например, 'te 0/0/10'.
6
