17. НАСТРОЙКА BFD
Bidirectional Forwarding Detection (BFD) - протокол, позволяющий быстро обнаруживать
проблемы связности маршрутизаторов на IP-уровне и, таким образом, обеспечивать
быструю сходимость протоколов. Следует отметить, что для работы BFD между элементами
должна быть связность по портам 3785, 3784, 4784. Впоследствии сконфигурированную BFD
сессию можно активировать как на протоколах IGP и EGP, так и на LDP. Больше
информации в RFC 5880.
IMPORTANT
Рекомендуется первоначально сконфигурировать профиль BFD-сессии,
а только потом активировать надстройку bfd fast-detect на протоколе.
Проверить, используются ли на соответствующей BFD-сессии
параметры сконфигурированного профиля либо глобальные
настройки, можно командой show bfd neighbors.
17.1. bfd session
Данная команда позволяет создать в конфигурации профиль BFD-сессии.
Отрицательная форма команды удаляет профиль BFD-сессии.
Синтаксис
bfd session STRING
no bfd session STRING
Параметры
• STRING (1-64) — имя BFD-сессии.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# bfd session test
0/ME5100:example_router01(config-session)#
17.2. address-family destination
Данная команда позволяет задать IPv4/IPv6-адрес назначения.
Отрицательная форма команды удаляет из конфигурации IPv4/IPv6 адрес назначения BFD
сессии.
430
