Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# level level-2
0/ME5100:example_router01(config-level)# authentication-key KEY
0/ME5100:example_router01(config-level)#
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# level level-2
0/ME5100:example_router01(config-level)# authentication-key KEY
0/ME5100:example_router01(config-level)#
12.6. authentication-type
В режиме конфигурации определенного уровня IS-IS для всего протокола (config-router-isis-
level и config-router-isis-vrf-level) данная команда задает тип аутентификации.
В режиме конфигурации определенного уровня IS-IS для интерфейса (config-router-isis-
interface и config-router-isis-vrf-interface) данная команда задает тип аутентификации.
В режиме конфигурации определенного уровня IS-IS для всего протокола (config-router-isis-
level и config-router-isis-vrf-level) отрицательная форма команды возвращает значение по
умолчанию (none).
В режиме конфигурации определенного уровня IS-IS для интерфейса (config-router-isis-
interface и config-router-isis-vrf-interface) отрицательная форма команды возвращает
значение по умолчанию (none).
Синтаксис
authentication-type { hmac-md5 | hmacsha1 | hmacsha256 | hmacsha384 | hmacsha512 |
none | simple-password } [no] authentication-type
Параметры
• { hmac-md5 | hmacsha1 | hmacsha256 | hmacsha384 | hmacsha512 | none | simple-
password } — способ аутентификации.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface
config-router-isis-interface-level
config-router-isis-level
config-router-isis-vrf-interface
config-router-isis-vrf-interface-level
config-router-isis-vrf-level
194
