![Eltex ME5100 [197/670] Show ospfv2 database](/views2/1569351/page197/bgc5.png)
• VRF_NAME — имя Virtual Routing and Forwarding сущности.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show ospfv2 area link-state
Thu Jul 20 16:41:36 2017
Ê Routing Process: test, with ID 33.33.33.33
Ê Area 0.0.0.0, up
Ê Link ID ADV Router Age Seq# Checksum Type
Ê ----------------- -------------- ---------- ----------- ----------- -----
Ê 33.33.33.33 33.33.33.33 00:28:47 0x80000001 0x00008689 router-lsa
Ê 11.11.11.11 33.33.33.33 00:28:34 0x80000001 0x0000A109 summary-lsa
Ê Area 0.0.0.1, up
Ê Link ID ADV Router Age Seq# Checksum Type
Ê ----------------- -------------- ---------- ----------- ----------- -----
Ê 22.22.22.22 22.22.22.22 00:28:40 0x80000005 0x000043D2 router-lsa
Ê 33.33.33.33 33.33.33.33 00:28:34 0x80000004 0x0000CD09 router-lsa
Ê 0.0.0.0 33.33.33.33 00:28:47 0x80000001 0x000093E2 summary-lsa
11.67. show ospfv2 database
Данная команда выводит полную информацию по OSPFv2 Link-State Database (OSPFv2 LSDB).
Синтаксис
show ospfv2 [vrf { all | VRF_NAME }] database [detailed]
Параметры
• VRF_NAME — имя Virtual Routing and Forwarding сущности;
• detailed — параметр для вывода детальной информации по OSPFv2 LSDB.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show ospfv2 database
176
