set dscp DSCP
no set dscp
Параметры
• DSCP — числовое значение в десятичном формате (0..63)
Необходимый уровень привилегий
p10
Командный режим
config-qos-mpls-to-dscp-ingress-map-mpls-tc
config-qos-tc-map-mpls-tc
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# mpls-tc 7
0/ME5100:example_router01(config-mpls-tc)# set dscp 56
0/ME5100:example_router01(config-mpls-tc)#
23.24. set dscp-both
Команда позволяет установить значение DSCP передаваемым IPv4 и IPv6 пакетам.
Отрицательная форма команды удаляет настройку.
Синтаксис
set dscp-both DSCP
no set dscp-both
Параметры
• DSCP — числовое значение в десятичном формате (0..63)
Необходимый уровень привилегий
p10
Командный режим
config-qos-tc-map-dscp-both
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# dscp-both 16
0/ME5100:example_router01(config-dscp-both)# set dscp-both 32
0/ME5100:example_router01(config-dscp-both)#
508
