Eltex ME5100 [145/670] Bfd fast detect
![Eltex ME5100 [145/670] Bfd fast detect](/views2/1569351/page145/bg91.png)
Синтаксис
[no] address-family { ipv4 | ipv6 } { multicast | unicast }
Параметры
• ipv4
• ipv6
• multicast
• unicast
Необходимый уровень привилегий
p10
Командный режим
configure
Пример
0/ME5100:example_router01(config)# router static
0/ME5100:example_router01(config-static)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)#
10.3. bfd fast-detect
Включение протокола быстрого обнаружения отказов BFD для статического маршрута.
Данная команда инициирует создание BFD-сессии с устройством, адрес которого указан в
качестве nexthop для текущего маршрута. При переходе BFD-сессии в неактивное состояние
маршрут также будет удален из числа активных до следующего поднятия сессии. Трафик по
неактивном маршруту также перестанет направляться.
Отрицательная форма команды отключает использование этого протокола.
Синтаксис
[no] bfd fast-detect
Параметры
Данная команда не содержит параметров.
Необходимый уровень привилегий
p10
Командный режим
config-router-static-destination-interface
Пример
124
