Eltex ME5100 [236/670] Lsp max size
![Eltex ME5100 [236/670] Lsp max size](/views2/1569351/page236/bgec.png)
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface-level
config-router-isis-vrf-interface-level
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# level level-2
0/ME5100:example_router01(config-level)# lsp-interval 10
0/ME5100:example_router01(config-level)#
12.39. lsp-max-size
Команда задает максимальный размер протокольных сообщений (LSP, SNP) отсылаемых
маршрутизатором в заданном уровне (level)
Отрицательная форма команды возвращает значение по умолчанию (1492)
Синтаксис
lsp-max-size BYTES
no lsp-max-size
Параметры
• BYTES — максимальный размер пакета в байтах (512..16000)
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-level
config-router-isis-vrf-level
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# level level-2
0/ME5100:example_router01(config-level)# lsp-max-size 1600
12.40. match nexthop
Команда задает префикс для фильтрации маршрутов по nexthop в заданном правиле
редистрибуции.
215
