Командный режим
config
Пример
0/ME5100:example_router01(config)# radius-server host 192.168.16.245 vrf mgmt-intf
0/ME5100:example_router01(config-host)#
5.25. radius-server retransmit
Данная команда задает количество попыток соединения с RADIUS-сервером.
Отрицательная форма команды устанавливает значение по умолчанию (3 попытки).
Синтаксис
radius-server retransmit RETRIES
[no] radius-server retransmit
Параметры
• RETRIES — количество попыток установления соединения, принимает значения 1..10.
Командный режим
config
Пример
0/ME5100:example_router01(config)# radius-server retransmit 5
5.26. radius-server timeout
Данная команда задает время ожидания ответа от RADIUS-серверов, в секундах.
Отрицательная форма команды устанавливает значение по умолчанию (3 секунды).
Синтаксис
radius-server timeout SECS
[no] radius-server timeout
Параметры
• SECS — время ожидания ответа от сервера, принимает значение 1..30 сек.
Командный режим
config
Пример
0/ME5100:example_router01(config)# radius-server timeout 20
64
