Командный режим
GLOBAL, ALL-CONFIG
Пример
0/ME5100:example_router01# history 10
Ê 30 history 50
Ê 31 history 20
Ê 32 end
Ê 33 sh run
Ê 34 history
Ê 35 history 10
Ê 36 show running-config router isis
Ê 37 show running-config aaa
Ê 38 show running-config lldp
Ê 39 history 10
0/ME5100:example_router01#
2.5. logout
Данной командой завершается текущий сеанс работы пользователя с интерфейсом
командной строки CLI.
Синтаксис
logout
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p1
Командный режим
GLOBAL, ALL-CONFIG
Пример
0/ME5100:example_router01# logout
Connection closed by foreign host.
2.6. ping
Данная команда используется для проверки доступности указанного сетевого устройства по
протоколу IPv4. Для проверки используется метод ICMP echo request.
Синтаксис
ping DST_IP [ count COUNT ] [ donotfrag ] [ interval INT ] [ size SIZE ] [ source SRC_IP ] [
11
