Eltex ME5100 [40/670] Show system
![Eltex ME5100 [40/670] Show system](/views2/1569351/page40/bg28.png)
0/ME5100:example_router01# show redundancy
Mon May 8 15:12:16 2017
This unit (0/ME5100) is in STANDALONE role
2.16. show system
Данной командой осуществляется просмотр общей информации об устройстве.
Синтаксис
show system
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show system
Tue Sep 19 02:47:40 2017
Ê System type: Eltex ME5100 carrier router
Ê System name: example_router01
Ê System software: Eltex Network OS for ME5k version 1.7.0.253R
Ê System uptime: 0 hours, 49 minutes, 24 seconds
Ê System restarted at: Tue Sep 19 01:58:16 2017
Ê System MAC address: a8:f9:4b:8b:2b:80
Ê Power supply 1 is present, status ON
Ê Power supply 2 is not present
Ê System has no active/unconfirmed alarms
2.17. show system environment
Данной командой осуществляется вывод показаний температурных датчиков устройства и
просмотр информации о состоянии вентиляторов устройства.
Синтаксис
show system environment
Параметры
Команда не содержит аргументов.
19
