![Eltex ME5100 [46/670] Terminal datadump](/views2/1569351/page46/bg2e.png)
• HOST_IPv4 — адрес узла, к которому будет производиться подключение;
• escape STRING — Escape-последовательность, при вводе которой сессия будет
разорвана;
• interface SRC_IP — интерфейс устройства, с адреса которого будет устанавливаться
сессия;
• port PORT — номер TCP-порта, на который будет устанавливаться сессия, по
умолчанию 22;
• vrf VRF — имя экземпляра VRF.
Необходимый уровень привилегий
p1
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# telnet 192.168.17.150
Entering character mode
Escape character is '^]'.
DR30-17-150 login: admin
Password:
********************************************
* Welcome to ME5000 *
********************************************
0/FMC0:DR30-17-150#
2.25. terminal datadump
Команда используется для выключения постраничного режима вывода данных в сессии
CLI. Команда действует только на текущую сессию CLI. Использование отрицательной
формы команды включает постраничный режим вывода данных.
Синтаксис
[no] terminal datadump
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p1
25
