Eltex ME5100 [388/670] Bfd fast detect
![Eltex ME5100 [388/670] Bfd fast detect](/views2/1569351/page388/bg184.png)
Командный режим
config-mpls-ldp
Пример
0/ME5100:example_router01(config)# mpls
0/ME5100:example_router01(config-mpls)# ldp
0/ME5100:example_router01(config-ldp)# address-family ipv4 unicast redistribution
connected Redist-Connected
0/ME5100:example_router01(config-connected)#
14.3. bfd fast-detect
Команда включает механизм BFD (Bidirectional Forwarding Detection) для LDP сессий на
указанном интерфейсе, либо targeted сессии. Этот механизм предназначен для ускорения
сходимости протокола LDP.
Отрицательная форма команды отключает механизм BFD.
Синтаксис
[no] bfd fast-detect
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-mpls-ldp-discovery-interface
config-mpls-ldp-neighbor
Пример
0/ME5100:example_router01(config)# mpls
0/ME5100:example_router01(config-mpls)# ldp
0/ME5100:example_router01(config-ldp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# bfd fast-detect
0/ME5100:example_router01(config-neighbor)#
14.4. discovery interface
Команда включает обнаружение LDP соседей для указанного интерфейса и входит в режим
конфигурирования дополнительных параметров.
Отрицательная форма команды выключает обнаружение на интерфейсе и удаляет всю
связанную конфигурацию.
367
