dscp DSCP_VAL
no dscp
Параметры
• DSCP_VAL — значение DSCP для пакетов, принимает значения 0..63.
Необходимый уровень привилегий
p15
Командный режим
config-ssh-server-vrf
config-telnet-server-vrf
Пример
0/ME5100:example_router01(config)# telnet server vrf default
0/ME5100:example_router01(config-vrf)# dscp 32
5.8. enable
Данная команда позволяет перейти в режим задания пароля (config-enable) для смены
привилегий пользователя на указанный уровень. Отрицательная форма команды удаляет
соответствующий раздел конфигурации вместе с паролем, если он был сконфигурирован.
Синтаксис
[no] enable { p1 | p2 | .. | p14 | p15 }
Параметры
• p1..p15 — уровни привилегий, для которых будет задаваться пароль.
Необходимый уровень привилегий
p15
Командный режим
config
Пример
0/ME5100:example_router01(config)# enable p15
0/ME5100:example_router01(config-enable)# password enable-15
NOTE
Для применения конфигурации раздела enable требуется обязательное
задание пароля внутри данного раздела командой 'password'.
