13.74. router bgp
Команда создает процесс BGP маршрутизации с заданным номером автономной системы
(AS) и переходит в режим конфигурации этого процесса (config-router-bgp).
Отрицательная форма команды удаляет данный процесс.
Синтаксис
[no] router bgp INTEGER
Параметры
• INTEGER — номер автономной системы процесса BGP маршрутизации. Диапазон
допустимых значений: 0-4294967295.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)#
13.75. send-community
Команда включает отправку BGP community атрибута в анонсах (UPDATE) к указанному
соседу.
Отрицательная форма команды возвращает поведение по умолчанию, атрибут community
из анонсов удаляется.
Синтаксис
[no] send-community
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
308
