Eltex ME5100 [467/670] Show pim interface
![Eltex ME5200 [467/670] Show pim interface](/views2/1569351/page467/bg1d3.png)
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show pim group-map
Tue Sep 12 10:19:02 2017
Ê IP PIM Group Mapping Table
Ê (* indicates group mappings being used)
Ê Group Range Proto Client RP address
Ê -------------------------- ------ ------- ----------------
Ê 239.1.200.0/21* asm config 10.0.0.1
Ê 225.54.0.0/16* asm config 23.23.23.23
Ê 232.1.1.1/32 ssm config 0.0.0.0
Ê 233.7.70.0/24* asm config 10.0.0.1
Ê 232.0.0.0/8* ssm config 0.0.0.0
Ê 239.1.128.0/24* asm config 10.0.0.1
Ê 239.0.0.0/21* asm config 23.23.23.23
Ê 239.0.0.0/8* asm config 23.23.23.23
18.18. show pim interface
Вывод информации о состоянии PIM протокола на интерфейсах.
Синтаксис
show pim interface [ ipv4 | ipv6 ]
Параметры
• ipv4 — фильтрация вывода информации для IPv4 address-family;
• ipv6 — фильтрация вывода информации для IPv6 address-family.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
446
