Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-redistribution
config-router-ospfv2-vrf-redistribution
config-router-ospfv3-redistribution
config-router-ospfv3-vrf-redistribution
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution connected CONNECTED
0/ME5100:example_router01(config-connected)# match prefix 10.1.1.1/32
0/ME5100:example_router01(config-connected)#
11.35. match tag
Команда включает фильтрацию перераспределяемых static-маршрутов по tag
Отрицательная форма команды отключает фильтрацию
Синтаксис
match tag TAG
no match tag
Параметры
• TAG — числовое значение тэга (1..65535)
Необходимый уровень привилегий
p10
Командный режим
config-router-ospfv2-redistribution-static
config-router-ospfv2-vrf-redistribution-static
config-router-ospfv3-redistribution-static
config-router-ospfv3-vrf-redistribution-static
Пример
0/ME5100:example_router01(config)# router ospfv2 PROCESS_NAME
0/ME5100:example_router01(config-ospfv2)# redistribution static STATIC
0/ME5100:example_router01(config-static)# match tag 500
0/ME5100:example_router01(config-static)#
153
