![Eltex ME5200 [497/670] Lldp interface](/views2/1569351/page497/bg1f1.png)
0/ME5100:example_router01(config)# lldp hold-multiplier 3
21.5. lldp interface
Данная команда включает протокол LLDP на интерфейсе, отрицательная форма команды
отключает протокол на интерфейсе.
Синтаксис
[no] lldp interface INTERFACE
Параметры
• INTERFACE — интерфейс, в формате <ТИП ИНТЕРФЕЙСА> <UNIT>/<SLOT>/<PORT>,
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# lldp interface tengigabitethernet 0/0/7
21.6. agent
Данная команда включает LLDP-агента соответствующего типа на интерфейсе и производит
переход в режим настройки этого агента. Отрицательная форма команды отключает LLDP-
агента
Синтаксис
[no] agent {nearest-bridge|nearest-customer-bridge|nearest-non-tpmr-bridge}
Необходимый уровень привилегий
p10
Командный режим
config-lldp-interface
Пример
0/ME5100:example_router01(config-tengigabitethernet)# agent nearest-bridge
21.7. neighbors-limit
Данная команда устанавливает максимальное количество соседей для LLDP-агента
