Eltex ME5100 [47/670] Traceroute
![Eltex ME5100 [47/670] Traceroute](/views2/1569351/page47/bg2f.png)
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# terminal datadump
2.26. traceroute
Данная команда используется для трассировки маршрута до указанного сетевого
устройства по протоколу IPv4.
Синтаксис
traceroute DST_IP [ maxttl MAXTTL ] [ minttl MINTTL ] [ probe PROBES ] [ protocol { icmp |
tcp | udp } ] [ source SRC_IP ] [ timeout TIMEOUT ] [ type TOS ] [ vrf VRF_NAME ]
Параметры
• DST_IP — адрес устройства, до которого будет выполняться трассировка;
• maxttl MAXTTL — максимальное значение TTL;
• minttl MINTTL — минимальное значение TTL;
• probe PROBES — количество запросов на каждом из шагов трассировки;
• protocol { icmp | tcp | udp } — протокол, используемый при выполнении
трассировки, по умолчанию UDP;
• source SRC_IP — IP-адрес отправителя, в качестве данного адреса может
использоваться только принадлежащий маршрутизатору IP;
• timeout TIMEOUT — время ожидания ответа, в секундах, принимает значения 1..10;
• type TOS — значение ToS (type of service) пакета, принимает значения 0..255;
• vrf VRF_NAME — имя экземпляра VRF.
Необходимый уровень привилегий
p1
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# traceroute 192.168.25.254 probe 4 timeout 3
Traceroute to 192.168.25.254 (192.168.25.254), 30 hops max, 60 byte packets
Ê1 192.168.16.1 (192.168.16.1) 4.666 ms 5.179 ms 5.835 ms 6.341 ms
Ê2 192.168.25.254 (192.168.25.254) 0.192 ms 0.194 ms 0.186 ms 0.159 ms
26
