Eltex ME5100 [296/670] Capability orf prefix
![Eltex ME5200 [296/670] Capability orf prefix](/views2/1569351/page296/bg128.png)
Командный режим
config-router-bgp
config-router-bgp-vrf
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# bgp update-groups enable
0/ME5100:example_router01(config-bgp)# no bgp update-groups enable
13.29. capability orf prefix
Команда включает ORF capability (Outbound Route Filtering) для указанного Address Family,
возможность отослать соседу, принять от него фильтр(ы) маршрутов. Данный функционал
позволяет фильтровать анонсы до отправки соседу в соответствии с его входящими
фильтрами.
Отрицательная форма команды выключает ORF capability.
Синтаксис
capability orf prefix { both | none | send | receive }
no capability orf prefix
Параметры
• none — ORF capability отключена;
• both — поддерживаются отправка и прием ORF фильтров;
• send — поддерживается только отправка ORF фильтров;
• receive — поддерживается только прием ORF фильтров.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor-address-family-ipv4-unicast
config-router-bgp-neighbor-address-family-ipv6-unicast
config-router-bgp-neighbor-address-family-vpnv4-unicast
config-router-bgp-neighbor-address-family-vpnv6-unicast
config-router-bgp-vrf-neighbor-address-family-ipv4-unicast
config-router-bgp-vrf-neighbor-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# capability orf prefix
275
