Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p15
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# reload system
Do you really want to reload system? (y/n): [n]
CAUTION
Перезагрузка системы приводит к полной переинициализации
устройства. Во время перезагрузки полностью прерывается прохождение
трафика через маршрутизатор.
2.10. show alarm
Данная команда выводит список активных аварий в системе.
Синтаксис
show alarm
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show alarm
Mon May 8 14:39:25 2017
Ê ID Code Type Device
Level Severity Timestamp (ago) Description
Ê ------ ------------------------------------------------- ------------- --------
------- --------- ---------------- ------------
Ê 1 Fan RPM range alarm trap me5100
yellow crit 01h31m34s 0 out of (80..11000)
14
