config-router-bgp-peer-group-address-family-l2vpn-vpls
config-router-bgp-peer-group-address-family-vpnv4-unicast
config-router-bgp-peer-group-address-family-vpnv6-unicast
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-neighbor-address-family-ipv4-unicast
config-router-bgp-vrf-neighbor-address-family-ipv6-unicast
config-router-bgp-vrf-peer-group-address-family-ipv4-unicast
config-router-bgp-vrf-peer-group-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# shutdown
0/ME5100:example_router01(config-neighbor)# no shutdown
13.92. slow-peer
Команда помечает соседа как медленного и имеет смысл при включенной опции update-
groups. В этом случае UPDATE сообщения данному соседу шлются отдельно от соседей в этой
же update group для того, чтобы не замедлять обмен с остальными.
Отрицательная форма команды возвращает поведения по умолчанию, обмен с соседями в
одной update group происходит одновременно.
Синтаксис
[no] slow-peer
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-bgp-neighbor
config-router-bgp-peergroup
config-router-bgp-vrf-neighbor
config-router-bgp-vrf-peergroup
Пример
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# neighbor 10.0.0.10
0/ME5100:example_router01(config-neighbor)# slow-peer
0/ME5100:example_router01(config-neighbor)# no slow-peer
329
