ВВЕДЕНИЕ
Аннотация
В настоящем руководстве приведено описание команд CLI для администратора
маршрутизаторов ELTEX серии ME.
Интерфейс командной строки (Command Line Interface, CLI) — интерфейс, предназначенный
для управления, просмотра состояния и мониторинга устройства. Для работы потребуется
любая установленная на ПК программа, поддерживающая работу по протоколу Telnet, SSH
или прямое подключение через консольный порт (например, Putty/SecureCRT).
Целевая аудитория
Справочник команд CLI предназначен для технического персонала, выполняющего
настройку и мониторинг маршрутизаторов серии ME посредством интерфейса командной
строки (CLI). Квалификация технического персонала предполагает знание основ работы
стека протоколов TCP/IP и принципов построения IP/MPLS-сетей.
Условные обозначения
Таблица 1. Обозначения в примерах и описаниях команд
Обозначения Описание
command example
Моноширинным шрифтом приведены примеры ввода команд и
результатов их выполнения.
[ ] В квадратных скобках для команд указываются необязательные
параметры.
{ } В фигурных скобках для команд указываются возможные обязательные
параметры, приведенные списком. Необходимо выбрать один из
параметров.
| Данный знак в описании команды обозначает "или".
< > В угловых скобках для команд указывается имя параметра, тип и
значение которого объясняются в описании.
IMPORTANT
Примечания содержат важную информацию, советы или
рекомендации по использованию и настройке устройства.
CAUTION
Предупреждения информируют пользователя о ситуациях, которые могут
нанести вред устройству, привести к некорректной работе системы,
потере данных или нарушению прохождения и обработки трафика.
