Eltex ME5100 [241/670] Metric style
![Eltex ME5100 [241/670] Metric style](/views2/1569351/page241/bgf1.png)
протокола маршрутизации и значения метрики в конфигурации правила
редистрибуции;
• same — используется значение метрики исходного протокола маршрутизации;
• scale-down — используется значение метрики исходного протокола маршрутизации,
деленное на значение метрики в конфигурации правила редистрибуции;
• scale-up — используется значение метрики исходного протокола маршрутизации,
умноженное на значение метрики в конфигурации правила редистрибуции;
• truncate — используется меньшее из значений исходного протокола маршрутизации
и значения метрики в конфигурации правила редистрибуции.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-ipv4-unicast-redistribution
config-router-isis-address-family-ipv6-unicast-redistribution
config-router-isis-vrf-address-family-ipv4-unicast-redistribution
config-router-isis-vrf-address-family-ipv6-unicast-redistribution
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast redistribution bgp
RULE
0/ME5100:example_router01(config-bgp)# metric-conversion same
0/ME5100:example_router01(config-bgp)#
12.46. metric-style
Данная команда позволяет выбрать тип метрики, который будет использоваться в данном
IS-IS Level.
Отрицательная форма команды возвращает значение по умолчанию (both).
Синтаксис
metric-style { both | narrow | wide }
[no] metric-style
Параметры
• both — параметр, который позволяет использовать и wide и narrow метрики;
• narrow — параметр, который позволяет использовать только narrow метрику;
• wide — параметр, который позволяет использовать только wide метрику.
Необходимый уровень привилегий
p10
220
