• confirmed — включение отката устройства на предыдущую версию ПО при не
подтверждении вновь установленного командой 'firmware confirm' в течение
заданного времени.
• SECONDS — время задержки подтверждения вновь установленного ПО в секундах (0-
86400).
Необходимый уровень привилегий
p15
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# show firmware
Tue May 16 16:46:09 2017
Ê Unit Image Running Boot Version Date
Ê --------- ------ -------- ------------- --------------------- ---------------------
Ê 0/ME5100 0 Yes * 1.5.0.220R 15-May-2017 11:17:03
Ê 0/ME5100 1 No 1.5.0.221R 15-May-2017 23:58:34
0/ME5100:example_router01# firmware select alternate
0/ME5100:example_router01# show firmware
Tue May 16 16:47:54 2017
Ê Unit Image Running Boot Version Date
Ê --------- ------ -------- ------------- --------------------- ---------------------
Ê 0/ME5100 0 Yes FALLBACK 1.5.0.220R 15-May-2017 11:17:03
Ê 0/ME5100 1 No NOT TESTED* 1.5.0.221R 15-May-2017 23:58:34
0/ME5100:example_router01#
IMPORTANT
При скачивании ПО командой 'copy' новая версия всегда
устанавливается в альтернативный образ; после скачивания ПО
следует выбрать альтернативный образ в качестве загрузочного и
перезагрузить устройство командой 'reload system'. После
перезагрузки следует подтвердить работоспособность нового ПО
командой 'firmware confirm' - данной командой подтверждается выбор
нового образа и раздел становится загрузочным на постоянной основе.
Без использования 'firmware confirm' при последующей перезагрузке
произойдёт обратное переключение активного и альтернативного
образов и будет загружена предыдущая версия ПО.
3.12. interval
Данной командой производится включение и настройка периодической выгрузки файла
конфигурации на удаленный сервер. Команда применяется в режиме настройки элемента
резервирования конфигурации "backup to".
36
