Eltex ME5100 [96/670] Clock set
![Eltex ME5100 [96/670] Clock set](/views2/1569351/page96/bg60.png)
0/ME5100:example_router01# clock read-calendar
6.3. clock set
Данная команда устанавливает время и дату в программных часах системы.
Синтаксис
clock set HH:MM:SS DAY MONTH YEAR
Параметры
• HH:MM:SS — время в 24-часовом формате — часы, минуты, секунды.
• DAY — день месяца, 1-31.
• MONTH — месяц в текстовом виде. Допустимые параметры: January, February, March,
April, May, June, July, August, September, October, November, December. Значение
является регистронезависимым.
Необходимый уровень привилегий
p10
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# clock set 12:11:00 8 may 2017
6.4. clock update-calendar
Данная команда записывает в аппаратные часы устройства значение программных часов.
Синтаксис
clock update-calendar
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
GLOBAL
Пример
0/ME5100:example_router01# clock update-calendar
75
