22. НАСТРОЙКА СПИСКОВ ДОСТУПА ACL
Маршрутизаторы серии ME поддерживают списки доступа ACL (Access Control Lists). В
данном разделе приведены соответствующие команды конфигурации.
22.1. action
Команда определяет, будут ли пакеты в указанном правиле (entry) списка доступа
разрешены либо запрещены.
Отрицательная форма команды удаляет настройку.
Синтаксис
action { permit | deny }
no action
Параметры
• permit — разрешает пакет
• deny — запрещает пакет
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-entry)# action deny
22.2. destination
Команда задает префикс для сравнения IP-адреса назначения пакета в правиле списка
доступа.
Отрицательная форма команды возвращает значение по умолчанию (any).
Синтаксис
destination { IPv4_ADDRESS | IPv4_PREFIX | IPv4_WILDCARD | any }
no destination
Параметры
• IPv4_ADDRESS — IPv4-адрес (A.B.C.D)
• IPv4_PREFIX — IPv4-префикс (A.B.C.D/N)
486
