Eltex ME5100 [524/670] Multicast rate
![Eltex ME5100 [524/670] Multicast rate](/views2/1569351/page524/bg20c.png)
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# mpls-to-dscp ingress rewrite
0/ME5100:example_router01(config-qos)#
23.15. multicast rate
Команда задает ограничение полосы пропускания передаваемого трафика IP Multicast в
профиле шторм-контроля. Используя параметр burst, возможно задать размер допустимых
вспышек трафика.
Отрицательная форма команды убирает ограничение.
Синтаксис
multicast rate KBPS [ burst KBITS ]
no multicast rate
Параметры
• KBPS — ограничение в килобитах в секунду (64..300000000)
• KBITS — размер в килобитах (0..33292)
Необходимый уровень привилегий
p10
Командный режим
config-qos-storm-control
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# storm-control Test
0/ME5100:example_router01(config-storm-control)# multicast rate 1000 burst 16000
0/ME5100:example_router01(config-storm-control)#
23.16. policy-map
Команда создает политику (Policy Map) и входит в режим ее конфигурирования. Политики
предназначены для управления трафиком различных классов и могут быть применены к
сабинтерфейсам.
Отрицательная форма команды удаляет политику.
Синтаксис
[no] policy-map POLICY_MAP
Параметры
• POLICY_MAP — имя политики. Строка допустимой длины: 1..63
503
