![Eltex ME5100 [510/670] Fragments](/views2/1569351/page510/bg1fe.png)
22.6. fragments
Команда указывает на то, что в данное правило попадают фрагментированные пакеты.
Отрицательная форма команды удаляет условие.
Синтаксис
[no] fragments
Параметры
Команда не содержит аргументов
Необходимый уровень привилегий
p10
Командный режим
config-ipv4-access-list-entry
Пример
0/FMC0:example_router01(config)# ipv4 access-list List1
0/FMC0:example_router01(config-access-list)# entry 10
0/FMC0:example_router01(config-access-entry)# fragments
0/FMC0:example_router01(config-access-entry)#
22.7. ipv4 access-list
Команда создает именованный список доступа (Access Control List) и входит в режим его
конфигурирования.
Отрицательная форма команды удаляет список и всю вложенную конфигурацию.
Синтаксис
ipv4 access-list ACCESS-LIST_NAME
no ipv4 access-list
Параметры
• ACCESS-LIST_NAME — строковое имя списка доступа (1..32)
Необходимый уровень привилегий
p10
Командный режим
config
Пример
489
