![Eltex ME5100 [338/670] Show bgp](/views2/1569351/page338/bg152.png)
0/ME5100:example_router01(config)# router bgp 65535
0/ME5100:example_router01(config-bgp)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# redistribution connected Redist-Connected
0/ME5100:example_router01(config-connected)# set weight 150
0/ME5100:example_router01(config-connected)# no set weight
0/ME5100:example_router01(config-connected)#
13.84. show bgp
Команда выводит список BGP маршрутов (BGP RIB). Использование параметров позволяет
вывести маршруты из определенных AFI/SAFI/VRF. Без указания параметров команда
выводит IPv4 unicast маршруты из глобальной таблицы (vrf default).
Синтаксис
show bgp [ vrf { all | VRF_NAME } ] [ all | ipv4 [ all | unicast ] | ipv6 [ all | unicast ] | l2vpn
[ all | vpls ] | vpnv4 [ all | unicast ] ]
Параметры
• all — позволяет выводить маршруты из всех AFI/SAFI/VRF;
• ipv4 — IPv4 AFI;
• ipv6 — IPv6 AFI;
• l2vpn — L2VPN AFI;
• unicast — Unicast SAFI;
• vpls — VPLS SAFI (Virtual Private LAN Services);
• vpnv4 — VPNv4 AFI;
• vrf — выводит маршруты из VRF;
• VRF_NAME — имя VRF.
Необходимый уровень привилегий
p2
Командный режим
GLOBAL
Пример
317
