![Eltex ME5100 [535/670] Tc map](/views2/1569351/page535/bg217.png)
23.33. tc
Команда назначает внутренний класс трафику, удовлетворяющему заданному условию.
Значение класса может быть от 0 до 7, является внутренним для устройства параметром и
используется в Class Map.
Отрицательная форма команды удаляет значение.
Синтаксис
tc TRAFFIC_CLASS
no tc
Параметры
• TRAFFIC_CLASS — внутренний класс трафика. Диапазон допустимых значений: 0..7.
Необходимый уровень привилегий
p10
Командный режим
config-qos-tc-map-dscp-both
config-qos-tc-map-ipv4-dscp
config-qos-tc-map-ipv6-dscp
config-qos-tc-map-mpls-tc
config-qos-tc-map-vlan-pcp-inner
config-qos-tc-map-vlan-pcp-outer
Пример
0/ME5100:example_router01(config)# qos
0/ME5100:example_router01(config-qos)# tc-map 1
0/ME5100:example_router01(config-tc-map)# mpls-tc 7
0/ME5100:example_router01(config-mpls-tc)# tc 7
0/ME5100:example_router01(config-mpls-tc)# no tc
0/ME5100:example_router01(config-mpls-tc)#
23.34. tc-map
Команда создает внутренний классификатор трафика (Traffic Class Map) и переходит в
режим его конфигурирования. Внутренний классификатор позволяет назначать трафику
различные значения внутреннего класса (Traffic Class) в зависимости от различных
параметров пакета.
Отрицательная форма команды удаляет классификатор.
Синтаксис
[no] tc-map TC_MAP_INDEX
514
