Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# sa-filter in 1
0/ME5200:example_router01(config-in)# rp-address 10.0.0.0/0.0.0.255
0/ME5200:example_router01(config-in)#
20.13. sa-filter in
Команда создает нумерованный элемент списка фильтрации входящих SA-сообщений.
Отрицательная форма команды удаляет соответствующий элемент.
Синтаксис
sa-filter in SEQ_NUM
no sa-filter in
Параметры
• SEQ_NUM — порядковый номер элемента списка фильтрации (1..4294967295)
Необходимый уровень привилегий
p10
Командный режим
config-router-msdp-peer
config-router-msdp-vrf-peer
Пример
0/ME5200:example_router01(config)# router msdp
0/ME5200:example_router01(config-msdp)# peer 10.0.0.1
0/ME5200:example_router01(config-peer)# sa-filter in 1
0/ME5200:example_router01(config-in)#
20.14. sa-filter out
Команда создает нумерованный элемент списка фильтрации отправляемых SA сообщений.
Отрицательная форма команды удаляет соответствующий элемент.
Синтаксис
sa-filter out SEQ_NUM
no sa-filter out
Параметры
• SEQ_NUM — порядковый номер элемента списка фильтрации (1..4294967295)
470
