Eltex ME5100 [105/670] Logging buffered severity
![Eltex ME5000 [105/670] Logging buffered severity](/views2/1569351/page105/bg69.png)
ротации. Может принимать значения от 1 до 1000.
Необходимый уровень привилегий
p10
Командный режим
config
Пример
0/ME5100:example_router01(config)# logging buffered rotate 20
0/ME5100:example_router01(config-host)# tcp 513
IMPORTANT
Команду рекомендуется использовать совместно с logging buffered
size. На системах, находящихся в эксплуатации, не следует задавать
значения более 10; вместо этого рекомендуется использование
удаленных серверов журналирования.
7.5. logging buffered severity
Данная команда задает минимальную степень важности (severity) сообщений, сохраняемых
в локальном журнале устройства.
Заданная степень важности используется в качестве фильтра — все системные события,
имеющие важность равную или более высокую, чем заданная, подлежат записи в журнал
событий устройства.
Согласно RFC3164 имеются следующие стандартные значения степеней важности:
Ê Numerical Severity
Ê Code
Ê 0 Emergency: system is unusable
Ê 1 Alert: action must be taken immediately
Ê 2 Critical: critical conditions
Ê 3 Error: error conditions
Ê 4 Warning: warning conditions
Ê 5 Notice: normal but significant condition
Ê 6 Informational: informational messages
Ê 7 Debug: debug-level messages
Использование отрицательной формы команды устанавливает значение по
умолчанию — debug(7).
Синтаксис
logging buffered severity { alert | crit | debug | emerg | error | info | none | notice |
warning }
84
