Eltex ME5100 [25/670] Работа с режимом конфигурирования
![Eltex ME5100 [25/670] Работа с режимом конфигурирования](/views2/1569351/page25/bg19.png)
Пример: использование фильтров
0/ME5100:example_router01# show running-config | begin "telnet server"
Thu Mar 23 12:03:57 2017
telnet server vrf mgmt-intf
exit
user admin
Ê password encrypted
$6$zMGqwSsQnYcfDrxH$6TGyBVbqUB8s2InhRT4QA5VADoCc4zGhILDKjTxgVt7H0TBzxmbwNkpkHSkHNAU9qC
zdQ/ZeonlI8EOrkII620
Ê privilege p15
exit
hostname example_router01#
1.4. Работа с режимом конфигурирования
В режиме конфигурирования командный интерфейс системы позволяет производить
настройку устройства. Переход в режим конфигурирования производится командой
configure. В режиме конфигурирования интерфейс принимает и распознает команды
настройки соответствующих разделов. Все введенные команды, в свою очередь, формируют
общую конфигурацию устройства.
Командный интерфейс системы работает с двумя экземплярами конфигурации устройства:
• Текущая конфигурация (running-config). Текущая конфигурация — это конфигурация,
которая в данный момент применена и используется на маршрутизаторе.
• Кандидат-конфигурация (candidate-config). Кандидат-конфигурация — это конфигурация,
которая включает в себя изменения, внесенные оператором в процессе сеанса
конфигурирования. Кандидат-конфигурация может быть применена в качестве
текущей.
IMPORTANT
Все введенные в режиме конфигурирования команды не
применяются по мере ввода, а заносятся в кандидат-конфигурацию
(candidate-config).
В обычном состоянии системы кандидат-конфигурация идентична текущей. После
внесения изменений в кандидат-конфигурацию её можно либо применить (скопировать в
текущую), либо отменить.
Таблица 3. Основные команды работы с экземплярами конфигурации
Команда Режим Действие команды
configure
global-view Перейти из глобального режима CLI в режим
конфигурирования.
4
