![Eltex ME5100 [233/670] Lfa remote](/views2/1569351/page233/bge9.png)
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-interface
config-router-isis-vrf-interface
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# interface tengigabitethernet 0/0/1
0/ME5100:example_router01(config-tengigabitethernet)# lfa protection disable
0/ME5100:example_router01(config-tengigabitethernet)#
12.34. lfa remote
Данная команда включает поддержку IS-IS IP Remote Loop-Free Alternate Fast Reroute (RLFA
FRR). При этом механизм LFA расчитывает альтернативные маршруты через удаленные
(indirectly connected) next-hop в случаях, когда отсутствуют directly connected альтернативы.
Больше информации в RFC 7490.
Отрицательная форма команды отключает поддержку IS-IS IP Remote Loop-Free Alternate Fast
Reroute.
Синтаксис
[no] lfa remote
Параметры
Команда не содержит аргументов.
Необходимый уровень привилегий
p10
Командный режим
config-router-isis-address-family-ipv4-unicast
config-router-isis-address-family-ipv6-unicast
config-router-isis-vrf-address-family-ipv4-unicast
config-router-isis-vrf-address-family-ipv6-unicast
Пример
0/ME5100:example_router01(config)# router isis PROCESS_NAME
0/ME5100:example_router01(config-isis)# address-family ipv4 unicast
0/ME5100:example_router01(config-unicast)# lfa remote
0/ME5100:example_router01(config-unicast)#
212
