Пример
0/ME5100:example_router01# show mpls ldp parameters
Thu Aug 17 07:39:06 2017
Ê LDP Parameters:
Ê Router ID: 2.2.2.2
Ê Transport address: 2.2.2.2
Ê Graceful Restart:
Ê Status: disabled
Ê Reconnect Timeout: 120 sec, Forwarding State Holdtime: 120 sec
Ê Neighbors:
Ê Peer address: 1.1.1.1
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 0 sec
Ê Peer address: 3.3.3.3
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 0 sec
Ê Peer address: 4.4.4.4
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 0 sec
Ê Peer address: 50.50.50.50
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 0 sec
Ê Interfaces:
Ê Interface Tengigabitethernet 0/1/4
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 15 sec
Ê Interface Tengigabitethernet 0/1/5
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 15 sec
Ê Interface Tengigabitethernet 0/1/6
Ê BFD status: disabled
Ê Holdtime interval: 40 sec
Ê Hello interval: 15 sec
384
