Ê IPv4 Address Family: enabled
Ê IPv6 Address Family: disabled
Ê Circuit level: level-2 (Interface circuit type is level-1-2)
Ê Level one:
Ê ID: 0000.0000.0001, ID Hostname: AR1, DR ID: none, Designated Hostname: none,
Configured metric: 10
Ê Level two:
Ê ID: 0000.0000.0001, ID Hostname: AR1, DR ID: none, Designated Hostname: none,
Configured metric: 10
Ê Tengigabitethernet 0/0/6
Ê Last up: 00h42m17s ago
Ê BFD Fast detect: IPv4 disabled, IPv6 disabled
Ê Operation state: up
Ê Disabled creating neighborhood on this interface: false
Ê Circuit 3 way: enabled
Ê Extended circuit id: 7
Ê T1 timer status: stopped
Ê Media Type: p2p
Ê IPv4 Address Family: enabled
Ê IPv6 Address Family: disabled
Ê Circuit level: level-2 (Interface circuit type is level-1-2)
Ê Level one:
Ê ID: 0000.0000.0001, ID Hostname: AR1, DR ID: none, Designated Hostname: none,
Configured metric: 20
Ê Level two:
Ê ID: 0000.0000.0003, ID Hostname: DR2_SRX100, DR ID: none, Designated Hostname:
none, Configured metric: 20
Ê Tengigabitethernet 0/0/5.12
Ê Last up: 00h42m17s ago
Ê BFD Fast detect: IPv4 enabled, IPv6 disabled
Ê Operation state: up
Ê Disabled creating neighborhood on this interface: false
Ê Circuit 3 way: enabled
Ê Extended circuit id: 89
Ê T1 timer status: stopped
Ê Media Type: broadcast
Ê IPv4 Address Family: enabled
Ê IPv6 Address Family: disabled
Ê Circuit level: level-2 (Interface circuit type is level-1-2)
Ê Level one:
Ê ID: none, ID Hostname: none, DR ID: none, Designated Hostname: none, Configured
metric: 10
Ê Level two:
247
