40 | English
1 609 929 T49 | (19.11.09) Bosch Power Tools
Product Features
The numbering of the components shown refers
to the representation of the power tool on the
graphic pages.
1 Sliding table
2 Table extension
3 Insert plate
4 Riving knife
5 Vacuum connection on the blade guard
6 Blade guard
7 Sticker for marking of the cutting line
8 Parallel guide
9 Table width enlargement
10 Parallel fence of the table width enlarge-
ment 9
11 Saw table
12 Handwheel for lowering and raising the saw
blade
13 Scale for clearance of the saw blade to the
parallel guide 8
14 EMERGENCY OFF button
15 Guide groove for parallel guide 8
16 Angle stop
17 Ring spanner (23 mm; 13 mm)
18 Auxiliary parallel fence (aluminium)
19 Fastening screw of saw-blade storage
20 Mounting holes
21 Guide groove for angle stop
22 Hold-down stick
23 Fastening knob for table extension 2
24 Locking lever of the sliding table
25 Fastening knob for parallel fence 10
26
Fastening knob for table width
enlargement
9
27 Storage for auxiliary parallel fence 18
28 Storage for parallel guide 8
29 Locking knob for adjustment of bevel angles
30 Safety flap of On/Off switch
31 Cable holder
32 Sawdust ejector
33 Storage for angle stop
34 Vacuum hose
35 Bottom plate
36 Hexagon bolt for fastening of the
riving knife 4
37 Insert-plate notches
38 Saw blade
39 Fixture for riving knife
40 Fastening kit for “blade guard”
41 Fastening kit for “table extension”
42 Rubber buffer
43 Guide rail of the angle stop
44 Locking knob on the angle guide
45 Fastening kit for “auxiliary parallel fence/an-
gle stop”
46 Clamping knob of the parallel guide
47 Profile rail
48 Fastening knobs for auxiliary parallel fence
(aluminium)
49 Auxiliary parallel fence (plastic)
50 Spindle lock lever
51 Clamping nut
52 Supporting/clamping flange
53 Tool spindle
54 Locking knob for bevel angle (horizontal)
55 Angle indicator on the angle guide
56 Angle indicator (vertical)
57 Scale for bevel angle (vertical)
58 Lens
59 Scale for clearance of the saw blade to the
parallel fence 10
60 ON pushbutton
61 Adjusting screw for setting the standard 90°
bevel angle
62 Adjusting screw for setting the standard 45°
bevel angle
63 Screw for angle indicator (vertical)
64 Nut for adjustment of the parallel-fence ten-
sioning force 8
65 Adjusting screws for sliding-table play
66 Adjusting screws for insert plate
67 Recessed grips
68 Fastening kit for “base unit”*
69 Base unit*
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
